Jupiter Designs is efficient manufacturer of PCB Layouts, Prototypes Designs, Pcb Fabrications, Rigid Pcb Boards, Assembly Layouts, Microprocessor Designs, Digital Hardware Design.Our professionals have sound knowledge of PCB layout design in high speed and complexity board, PCB assembly and fabrication of rigid and flexible PCB’s for the specifications of high reliability applications. They are experts in re-engineering, reverse engineering and card level testing (functional test). Besides, they are also experienced in all kinds of electronic components, devices and their mounting provision requirements.

Along with quality and timeliness of work, is another criteria that matters a lot to us.Our team members at JDT also have a high degree of overload job managing ability. No matter how heavy the workload is; our products always reach their desired place right on time. With our team of dedicated and expert staff members, we at JDT are also capable of deploying our manpower at customers’ place (if required), besides taking up the works at our place.

Design Samples

VIDEO GRAPHICS CARD/ COMMERCIAL


  • No OF LAYERS: 16
  • BOARD AREA: 12” X 12.8”
  • PROJECT DURATION: 45 DAYS
  • BGA PITCH: 0.5 mm
  • No OF COMPONENTS: 2200
  • TRACE WIDTH / AIRGAP: 4/4 MIL
  • MINIMUM VIA SIZE: 8 MIL
VIDEO GRAPHICS CARD/ COMMERCIAL
  • No OF LAYERS: 16
  • BOARD AREA: 12” X 12.8”
  • MINIMUM VIA SIZE: 8 MIL
  • No OF COMPONENTS: 2200
  • TRACE WIDTH / AIRGAP: 4/4 MIL
  • PROJECT DURATION: 45 DAYS
  • BGA PITCH: 0.5 mm

SOC Camera Card / INDUSTRIAL


  • No OF LAYERS: 14
  • BOARD AREA: 11” X 9.5”
  • PROJECT DURATION: 40 DAYS
  • BGA PITCH: 0.5 mm
  • No OF COMPONENTS: 1480
  • TRACE WIDTH / AIRGAP: 4/4 MIL
  • MINIMUM VIA SIZE: 8 MIL
SOC Camera Card / INDUSTRIAL
  • No OF LAYERS: 14
  • BOARD AREA: 11” X 9.5”
  • PROJECT DURATION: 40 DAYS
  • MINIMUM VIA SIZE: 8 MIL
  • No OF COMPONENTS: 1480
  • TRACE WIDTH / AIRGAP: 4/4 MIL
  • BGA PITCH: 0.5 mm

TV Card / MULTI MEDIA


  • No OF LAYERS: 10
  • BOARD AREA: 6” X 4”
  • PROJECT DURATION: 200 Hrs
  • BGA PITCH: 0.8 mm
  • No OF COMPONENTS: 906
  • No OF NETS: 2631
  • TRACE WIDTH / AIRGAP: 4 MIL
  • MINIMUM VIA SIZE: 10 MIL
TV Card / MULTI MEDIA
  • No OF LAYERS: 10
  • BOARD AREA: 6” X 4”
  • PROJECT DURATION: 200 Hrs
  • BGA PITCH: 0.8 mm
  • No OF COMPONENTS: 906
  • No OF NETS: 2631
  • TRACE WIDTH / AIRGAP: 4 MIL
  • MINIMUM VIA SIZE: 10 MIL

CONTROLLER CARD / SPACE APPLICATION


  • No OF LAYERS: 12
  • BOARD AREA: 11” X 5”
  • PROJECT DURATION: 256 Hrs
  • BGA PITCH: 0.8 mm
  • No OF COMPONENTS: 1175
  • No OF NETS: 4108
  • TRACE WIDTH / AIRGAP: 4/4 MIL
  • MINIMUM VIA SIZE: 10 MIL
CONTROLLER CARD / SPACE APPLICATION
  • No OF LAYERS: 12
  • BOARD AREA: 11” X 5”
  • PROJECT DURATION: 256 Hrs
  • BGA PITCH: 0.8 mm
  • No OF COMPONENTS: 1175
  • No OF NETS: 4108
  • TRACE WIDTH / AIRGAP: 4/4 MIL
  • MINIMUM VIA SIZE: 10 MIL





Switch Card / DEFENCE


  • No OF LAYERS: 10
  • BOARD AREA: 305 mm X 228 mm
  • PROJECT DURATION: 28 DAYS
  • BGA PITCH: 1.27 mm
  • No OF COMPONENTS: 1506
  • No OF NETS: 4717
  • TRACE WIDTH / AIRGAP: 6/6 MIL
  • MINIMUM VIA SIZE: 12 MIL
Switch Card / DEFENCE
  • No OF LAYERS: 10
  • BOARD AREA: 305 mm X 228 mm
  • PROJECT DURATION: 28 DAYS
  • BGA PITCH: 1.27 mm
  • No OF COMPONENTS: 1506
  • No OF NETS: 4717
  • TRACE WIDTH / AIRGAP: 6/6 MIL
  • MINIMUM VIA SIZE: 12 MIL

Telephone Exchange Card / Communication


  • No OF LAYERS: 6
  • BOARD AREA: 254 mm X 305 mm
  • PROJECT DURATION: 220 Hrs
  • BGA PITCH: 0.8 mm
  • No OF COMPONENTS: 712
  • No OF NETS: 2180
  • TRACE WIDTH / AIRGAP: 9 MIL
  • MINIMUM VIA SIZE: 16 MIL
  • SPECIAL REQUIREMENT: EMI / EMC
Telephone Exchange Card / Communication
  • No OF LAYERS: 6
  • BOARD AREA: 254 mm X 305 mm
  • PROJECT DURATION: 220 Hrs
  • BGA PITCH: 0.8 mm
  • No OF COMPONENTS: 712
  • No OF NETS: 2180
  • TRACE WIDTH / AIRGAP: 9 MIL
  • MINIMUM VIA SIZE: 16 MIL
  • SPECIAL REQUIREMENT:EMI/EMC





Digital card / Commercial Application


  • No OF LAYERS: 4
  • BOARD AREA: 216 mm X 38 mm
  • PROJECT DURATION: 90 Hrs
  • No OF COMPONENTS: 193
  • No OF NETS: 550
  • TRACE WIDTH / AIRGAP: 8 MIL
  • MINIMUM VIA SIZE: 16 MIL
Digital card / Commercial Application
  • No OF LAYERS: 4
  • BOARD AREA: 216 mm X 38 mm
  • PROJECT DURATION: 90 Hrs
  • No OF COMPONENTS: 193
  • No OF NETS: 550
  • TRACE WIDTH / AIRGAP: 8 MIL
  • MINIMUM VIA SIZE: 16 MIL

Power supply board / INDUSTRIAL


  • No OF LAYERS: 4
  • BOARD AREA: 140 mm X 135 mm
  • PROJECT DURATION: 140 Hrs
  • No OF COMPONENTS: 180
  • No OF NETS: 800
  • TRACE WIDTH / AIRGAP: 8 MIL
  • MINIMUM VIA SIZE: 12 MIL
Power Supply board / INDUSTRIAL
  • No OF LAYERS: 4
  • BOARD AREA: 140 mm X 135 mm
  • PROJECT DURATION: 140 Hrs
  • No OF COMPONENTS: 180
  • No OF NETS: 800
  • TRACE WIDTH / AIRGAP: 8 MIL
  • MINIMUM VIA SIZE: 12 MIL
